Multiwall Polycarbonate R Corner Profile
Polycarbonate
- Description
- Features
- Reviews
Turns a glazed plane through a vertical corner, joining two panels at an angle where an H profile cannot. Sized for 10mm multiwall panel.
Not a ridge detail - a roof ridge needs a purpose-made ridge profile, not a corner profile turned on its side.
In a polycarbonate glazing system the profiles exist so the panel can move. That is why they are dry-fit, why the screw goes through the panel in an oversized hole rather than into the profile, and why adhesive, putty and unapproved sealants void the panel warranty.
- Turns a glazed plane through a vertical corner, joining two panels at
- Sized for 10mm multiwall panel
- Clear finish
- Sold by the foot
- Dry-fit - no adhesive or putty at the joint
- Screw through the panel, not into the profile
- Oversized holes so the panel can move
- Part of a vented, draining glazing system
| Material | PC |
|---|---|
| Unit of Measure | Ft |
